Merida Crossway 10 V

Merida Crossway 10 V

Regular price €599,00 EUR
Regular price Sale price €599,00 EUR
Sale Sold out
Tax included.
Color
Frame Size



Highlights:
  • Aluminium frame
  • Suspension fork
  • 21 speed Shimano drivetrain
  • Adjustable stem
  • Suspension seatpost
  • Multiple fixing points for rear rack and mudguards
21 speed hybrid with front suspension fork Shimano chainset and freewheel.



The Crossway is the perfect blend of comfort, enjoyment and all around practicality, suitable for leisure rides or commuting. For ultimate adaptability, the Crossway can be equipped with mudguards, racks and kickstands.

SPECIFICATION

FRAME
  • DT - 6061 double butted technoformed aluminium. BSA BB standard, 135 x 9mm QR axle standard. Mounting points for rack, mudguards and kickstand. Max tyre size 700 x 42c
FORK
  • Suntour NEX; Coil; 63mm travel. Max tyre size: 700 x 50c
GEARS
  • 21
SHIFTERS
  • Shimano ST-EF500
FRONT DERAILLEUR
  • Shimano FD-TY510
REAR DERAILLEUR
  • Shimano RD-M310
BOTTOM BRACKET
  • FSA TH-7420ST, Cartridge Bearing
CHAIN
  • KMC NS8
CHAINSET
  • Shimano TY301; 48-38-28 tooth chainset. Crank length: 170mm (S), 175mm (M/L,XL)
CASSETTE
  • Shimano MF-TZ500; 14-28 teeth; 7 speed
BRAKE LEVER
  • Shimano ST-EF500
FRONT BRAKE
  • Promax MTV-117A V Brake
REAR BRAKE
  • Promax MTV-117A V Brake
GRIP
  • Merida EC
HANDLEBAR
  • Merida CC; steel; 620mm width; 30mm rise
STEM
  • Merida TK; aluminium; 25.4mm diameter; adjustable - Stem length: 100mm (all sizes)
HEAD SET
  • FSA TH888
PEDAL
  • VP Components, VPE-891
SADDLE
  • Merida Cross Sport
SEAT POST
  • Merida TK; 27.2mm diameter; 13mm setback; 40mm seatpost suspension travel
WHEEL SIZE
  • 700c
RIMS
  • Merida CC; 17mm inner rim width; aluminium
SPOKES
  • Steel UCP
FRONT HUB
  • Joytech JY-751DSE; 100x9mm; 32 spokes
REAR HUB
  • Joytech JY-752DSE; 135x9mm; 32 spokes
FRONT TYRE
  • Merida K1171; 700x40C; wire bead
REAR TYRE
  • Merida K1171; 700 x 40C; wire bead
COLOUR
  • Anthracite/Black
SEASON
  • 2023
